Cetop Valves, Subplates & Manifolds

At Catford Engineering we offer a wide range of hydraulic products. Browse our hydraulic Australian made Cetop Valves, Subplates & Manifolds.

If you require a quotation or have any questions, get in touch with our friendly hydraulic experts today.

*Cetop 3, 5 & 7 Solenoid Valves *Manual Solenoid
*Subplates *Manifolds *Coils *DIN *Plugs
*Sandwich *Valves *Endplates *Relief Cartridges

*NOTE: All prices stated within are exclusive of GST

Call Charles 0418 641 566

Lot 25, Mannanarie Road,
Jamestown SA PO Box 178 , Jamestown SA 5491

SANDWICH VALVES & ACCESSORIES

Sandwich Valve

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Max Pressure	Max Flow	Ports	Transition	Diagram
HDF-ES-1C	$	250 bar	20 Ipm	1/4″ BSPP	Closed	1
HDF-ES-1 LL	$	250 bar	20 Ipm	1/4″ BSPP	Closed	2
HDF-ES-4C	$	250 bar	20 Ipm	1/4″ BSPP	Open	3
HDF-ES-3C	$	250 bar	20 Ipm	1/4″ BSPP	A + B to T	4
HDF-ES-OC	$	250 bar	20 Ipm	1/4″ BSPP	Open	5
HDF-ES-OML	$	250 bar	20 Ipm	1/4″ BSPP	Open	6
AMF-MOP-25	$	250 bar	20 Ipm	1/4″ BSPP	Relief	7
AMF-HP2	$	200 bar	2cc	–	Hand Pump	8

Sandwich Valve HDF Coils

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Voltage	Amp Draw	Core Size	Length	Connector
B01-012C	$	12v DC	2.8 amp	13.8mm	41.2mm	DP-LED-DC
B01-024C	$	24v DC	1.4 amp	1 3.8mm	41.2mm	DP-LED-DC
B01-23OR	$	220v AC	0.17 amp	13.8mm	41.2mm	DP-LED-AC

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Voltage

Amp Draw

Core Size

Length

Connector

B01-012C

12v DC

2.8 amp

13.8mm

41.2mm

DP-LED-DC

B01-024C

24v DC

1.4 amp

1 3.8mm

41.2mm

DP-LED-DC

B01-23OR

220v AC

0.17 amp

13.8mm

41.2mm

DP-LED-AC

Sandwich Valve Endplates & Manifolds

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Material	Port	Description
PD1-03/32-0	$	Aluminium		End plate
PD1-03/32-5	$	Aluminium	3/8″ BSPP	Remote mount plate port
GE-01	$	Aluminium		Manual override knob for HDF valves
MAF-KIT-2	$	Aluminium		Remote mount mounting bracket

Sandwich Valve Bolt Kits

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Description
VIT-HDF-M6X55	$	Bolt Kit – 1 Section HDF/CS Valve
VIT-HDF-M6X100	$	Bolt Kit – 2 Section HDF/CS Valve
VIT-HDF-M6X133	$	Bolt Kit – 3 Section HDF/CS Valve
VIT-HDF-M6X163	$	Bolt Kit – 4 Section HDF/CS Valve
VIT-HDF-M6X 194	$	Bolt Kit – 5 Section HDF/CS Valve
VIT-HDF-M6X224	$	Bolt Kit – 6 Section HDF/CS Valve
VIT-HDF-M6X256	$	Bolt Kit – 7 Section HDF/CS Valve
VIT-HDF-M6X287	$	Bolt Kit – 8 Section HDF/CS Valve

Sandwich Valve

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Transition	Voltage	Max Flow	Max Pressure	Ports
CS-3C2-03-D12	$	Closed	12v	15 Ipm	200 bar	1/4″ BSPP
CS-3C2-03-D24	$	Closed	24v	15 Ipm	200 bar	1/4″ BSPP
CS-3C2-03-A22	$	Closed	220v	15 Ipm	200 bar	1/4″ BSPP
CS-3C4-03-D12	$	A + B open to T	12v	15 Ipm	200 bar	1/4″ BSPP
CS-3C4-03-D24	$	A + B open to T	24v	15 Ipm	200 bar	1/4″ BSPP
CS-3C4-03-A22	$	A + B open to T	220v	15 Ipm	200 bar	1/4″ BSPP
CS-C3B-03-D12	$	Open	12v	15 Ipm	200 bar	1/4″ BSPP
CS-C3B-03-D24	$	Open	24v	15 Ipm	200 bar	1/4″ BSPP
CS-C3B-03-A22	$	Open	220v	15 Ipm	200 bar	1/.4″ BSPP

Sandwich Valve Endplates & Manifolds

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Material	Port	Description
T0407	$	Aluminium	n/a	End plate
T0407-PT	$	Aluminium	9/16″ UNO	Remote mount plate port
CS-03-M	$	Aluminium	n/a	Manual override knob for CS valves

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Material

Port

Description

T0407

Aluminium

n/a

End plate

T0407-PT

Aluminium

9/16″ UNO

Remote mount plate port

CS-03-M

Aluminium

n/a

Manual override knob for CS valves

Coils

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Voltage	Amp Draw	Core Size	Length	Connector
CS-12V	$	12v DC	2.8 amp	13.2mm	37mm	DP-LED-DC
CS-24V	$	24v DC	1.4 amp	13.2mm	37mm	DP-LED-DC
CS-A22	$	220v AC	0.17 amp	13.2mm	37mm	DP-REC-AC

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Voltage

Amp Draw

Core Size

Length

Connector

CS-12V

12v DC

2.8 amp

13.2mm

37mm

DP-LED-DC

CS-24V

24v DC

1.4 amp

13.2mm

37mm

DP-LED-DC

CS-A22

220v AC

0.17 amp

13.2mm

37mm

DP-REC-AC

CETOP 3 SOLENOID & MANUAL VALVES

Aidro Cetop 3 Solenoid & Manual Valves

	SOLENOID	MANUAL
Nominal Flow Rate	60 Ipm	60 Ipm
Maximum Recommended Flow	80 Ipm	80 Ipm
Maximum Nominal Pressure P,A,B	350 bar	320 bar
Maximum Pressure on T Port	210 bar	100 bar
Duty Cycle	100%	n/a
(single valve)	M5x45mm (tighten to 8Nm)

Typical Diagrams

Typical rp-Q curves for valves HD3-ES-* in standard configuration. Measured with mineral oil at 32mm²/s and T=40°C.

Spool	P-A	P-B	A-T	B-T	P-T
1C	1	1	2	2	–
4C	3	3	4	4	1
OC	1	1	2	2	1
3C	1	1	2	2	–
1LL	1	1	2	2	–
1LLb	1	1	2	2	–
1ML		1	2	–	–
4ML	4	–	4	–	2
OML	–	1	2	–	1
3ML	–	–	2	–	–

Hydraulic Limit of Use

rp-Q characteristics limits for safe use of HD3-ES-* solenoid operated valves. Measured with mineral oil at 32mm²/s and T=40°C.

Spool	Limit	Spool	Limit
1C	1	1ML	1
4C	3	0ML	2
OC	2	1MLb	1
3C	2	1LLb	1
1LL	1	4MLb	3
3ML	2	0MLb	2
4ML	3	3MLb	2

HYDRAULIC FLUID

Seals and materials used on standard HD3-* valves are fully compatible with hydraulic
fluids of mineral base, upgrading with antifoaming and antioxidising agents.

The hydraulic fluid must be kept clear and filtered to ISO4406 class 19/17/14, or better,
and used in a recommended viscosity range from 10cSt to 60cSt.

Cetop 3 Solenoid Valves (AIDRO)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage
HD3-ES-0C-012C/10	$	12v DC
HD3-ES-0C-024C/10	$	24v DC
HD3-ES-0C-230A/10	$	230v AC
HD3-ES-0C-115A/10	$	115v AC
HD3-ES-1C-012C/10	$	1 2v DC
HD3-ES-1C-024C/10	$	24v DC
HD3-ES-1C-230A/10	$	230v AC
HD3-ES-1C-115A/10	$	115v AC
HD3-ES-3C-012C/10	$	12v DC
HD3-ES-3C-024C/10	$	24v DC
HD3-ES-3C-230A/10	$	230v AC
HD3-ES-3C-115A/10	$	115v AC
HD3-ES-4C-012C/10	$	1 2v DC
HD3-ES-4C-024C/10	$	24v DC
HD3-ES-4C-230A/10	$	230v AC
HD3-ES-4C-115A/10	$	115v AC
HD3-ES-1N-012C/10	$	1 2v DC
HD3-ES-1 N-024C/10	$	24v DC
HD3-ES-1N-230A/10	$	230v AC
HD3-ES-1N-115A/10	$	115v AC

Cetop 3 Solenoid Valves (AIDRO)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage
HD3-ES-OLL-012C/10	$	12v DC
HD3-ES-OLL-024C/10	$	24v DC
HD3-ES-OLL-230A/10	$	230v AC
HD3-ES-OLL-115A/10	$	115v AC
HD3-ES-OML-012C/10	$	12v DC
HD3-ES-OML-024C/10	$	24v DC
HD3-ES-OML-230A/10	$	230v AC
HD3-ES-OML-115A/10	$	115v AC
HD3-ES-1LL-012C/10	$	12v DC
HD3-ES-1LL-024C/10	$	24v DC
HD3-ES-1LL-230A/10	$	230v AC
HD3-ES-1LL-115A/10	$	115v AC
HD3-ES-1LLb-012C/10	$	12v DC
HD3-ES-1LLb-024C/10	$	24v DC
HD3-ES-1 LLb-230A/10	$	230v AC
HD3-ES-1LLb-115A/10	$	115v AC
HD3-ES-1ML-012C/10	$	12v DC
HD3-ES-1ML-024C/10	$	24v DC
HD3-ES-1ML-230A/10	$	230v AC
HD3-ES-1ML-115A/10	$	115v AC
HD3-ES-3ML-012C/10	$	12v DC
HD3-ES-3ML-024C/10	$	24v DC
HD3-ES-3ML-230A/10	$	230v AC
HD3-ES-3ML-115A/10	$	115v AC
HD3-ES-4ML-012C/10	$	12v DC
HD3-ES-4ML-024C/10	$	24v DC
HD3-ES-4ML-230A/10	$	230v AC
HD3-ES-4ML-115A/10	$	115v AC

Cetop 3 Manual Valves (AIDRO)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage
HD3-LO-0C/10	$	Manual
HD3-LO-0D/10	$	Manual w/ detent
HD3-LO-1C/10	$	Manual
HD3-LO-1D/10	$	Manual w/ detent
HD3-LO-3C/10	$	Manual
HD3-LO-3D/10	$	Manual w/ detent
HD3-LO-4C/10	$	Manual
HD3-LO-4D/10	$	Manual w/ detent
HD3-LO-0LL/10	$	Manual
HD3-LO-0N/10	$	Manual w/ detent
HD3-LO-1LL/10	$	Manual
HD3-LO-1N/10	$	Manual w/ detent

Aidro Cetop 3 Proportional Valve

	SOLENOID
Nominal Flow Rate	5, 16, 32 lpm
Maximum Nominal Pressure P,A,B	320 bar
Maximum Pressure on T Port	160 bar
Duty Cycle	100%
Bolts (single valve)	M5x45mm (tighten to 8Nm)

Valves type HD3-PS are operated by proportional solenoids that are rated for an average
maximum power of 13.5 watt.

The values of nominal maximum current are for coils type:

• R2 (2.3): l max = 2.4amp
• R3 (4.5): 1 max = 1.7amp
• R4 (13.4): l max = 1.0amp
• R5 (18.6): l max = 0.85amp

Currents to hydraulic proportional valves are normally supplied by an electronic driver based on
PWM mode of operation, and capable of full control of minimum and maximum values of current
for drivers type UED.

HYDRAULIC FLUID

Seals and materials used on standard HD3-* valves are fully compatible with hydraulic
fluids of mineral base, upgrading with antifoaming and antioxidising agents.

The hydraulic fluid must be kept clear and filtered to ISO4406 class 19/17/14, or better,
and used in a recommended viscosity range from 10cSt to 60cSt.

UNIVERSAL ELECTRONIC DRIVERS

Universal Electronic Driver

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Voltage	Input Signal	Output Current	Mounting	Controls
UED-KA	$	9-36v DC	0-5v, 0-10v, 4-20mA	0-3 amp	DIN 43650-A	1 solenoid
UED-D	$	9-36v DC	0-5v, 0-10v, 4-20mA	0-3 amp	DIN rail (open)	1 or 2 solenoid

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Voltage

Input Signal

Output Current

Mounting

Controls

UED-KA

9-36v DC

0-5v, 0-10v, 4-20mA

0-3 amp

DIN 43650-A

1 solenoid

UED-D

9-36v DC

0-5v, 0-10v, 4-20mA

0-3 amp

DIN rail (open)

1 or 2 solenoid

CETOP 3 PROPORTIONAL VALVES

Cetop 3 Proportional Valve - AIDRO (P,T,A,B blocked)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Flow	Coil	Nominal Max. Current	Diagram
Part #		Flow	Coil	Nominal Max. Current	Diagram	HD3-PS-105C-K-R2/10	$	5 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-105C-K-R4/10	$	5 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-1RC-K-R2/10	$	16 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-1RC-K-R4/10	$	16 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-1PC-K-R2/10	$	32 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-1PC-K-R4/10	$	32 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-105MLb-K-R2/10	$	5 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-105MLb-K-R4/10	$	5 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-1RMLb-K-R2/10	$	16 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-1RMLb-K-R4/10	$	16 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-1PMLb-K-R2/10	$	32 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-1PMLb-K-R4/10	$	32 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-105ML-K-R2/10	$	5 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-105ML-K-R4/10	$	5 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-1RML-K-R2/10	$	16 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-1RML-K-R4/10	$	16 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-1PML-K-R2/10	$	32 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-1PML-K-R4/10	$	32 Ipm, AP 10 bar	24v DC	1.0a / 13.40

Optional Coils

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage	Nominal Max. Current	Connection
Part #		Coil Voltage	Nominal Max. Current	Connection	BO3-12R2	$	12v DC	2.5a / 2.30	DIN 43650A
BO3-12R3	$	12v DC	2.7a / 4.40	DIN 43650A
BO3-24R4	$	24v DC	1a / 13.40	DIN 43650A
BO3-24R5	$	24v DC	1.29a / 18.60	DIN 43650A
BO3-12R2-D	$	12v DC	2.5a / 2.30	DEUTSCH
8O3-12R3-D	$	12v DC	2.7a / 4.40	DEUTSCH
BO3-24R4-D	$	24v DC	1a / 13.40	DEUTSCH
BO3-24R5-D	$	24v DC	1.29a / 18.60	DEUTSCH

Cetop 3 Proportional Valve - AIDRO (P blocked, A,B,T connected)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Flow	Coil Voltage	Nominal Max. Current
HD3-PS-305C-K-R2/10	$	5 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-305C-K-R4/10	$	5 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-3RC-K-R2/10	$	16 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-3RC-K-R4/10	$	16 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-3PC-K-R2/10	$	32 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-3PC-K-R4/10	$	32 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-305MLb-K-R2/10	$	5 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-305MLb-K-R4/10	$	5 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-3RMLb-K-R2/10	$	16 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-3RMLb-K-R4/10	$	16 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-3PMLb-K-R2/10	$	32 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-3PMLb-K-R4/10	$	32 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-305ML-K-R2/10	$	5 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-305ML-K-R4/10	$	5 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-3RML-K-R2/10	$	16 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-3RML-K-R4/10	$	16 Ipm, AP 10 bar	24v DC	1.0a / 13.40
HD3-PS-3PML-K-R2/10	$	32 Ipm, AP 10 bar	12v DC	2.5a / 2.30
HD3-PS-3PML-K-R4/10	$	32 Ipm, AP 10 bar	24v DC	1.0a / 13.40

Pressure Compensator Valve

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Description
AM3-LS-P3/20	$	3-way pressure compensator valve with load-sensing (more details on page 182)

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Description

AM3-LS-P3/20

3-way pressure compensator valve with load-sensing (more details on page 182)

CETOP 3 SOLENOID VALVES

Cetop 3 Valves w/ dual coils & LED DIN plugs

Recommended maximum flow 40 lpm @ 210 bar

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage	Max Press Tank
4DWG6-E-60-DC12-N-Z5L	$	12v DC	210 bar
4DWG6-E-60-DC24-N-Z5L	$	24v DC	210 bar
4DWG6-E-60-AC220-N-Z5L	$	240v AC	160 bar
4DWG6-H-60-DC12-N-Z5L	$	12v DC	210 bar
4DWG6-H-60-DC24-N-Z5L	$	24v DC	210 bar
4DWG6-H-60-AC220-N-Z5L	$	240v AC	160 bar
4DWG6-J-60-DC12-N-Z5L	$	12v DC	210 bar
4DWG6-J-60-DC24-N-Z5L	$	24v DC	210 bar
4DWG6-J-60-AC220-N-Z5L	$	240v AC	160 bar
4DWG6-G-60-DC12-N-Z5L	$	12v DC	210 bar
4DWG6-G-60-DC24-N-Z5L	$	24v DC	210 bar
4DWG6-G-60-AC220-N-Z5L	$	240v AC	160 bar

Cetop 3 Valves w/ single coils & LED DIN plugs

Recommended maximum flow 40 lpm @ 210 bar

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage	Max Press Tank
4DWG6-C-60-DC12-N-Z5	$	12v DC	210 bar
4DWG6-C-60-DC24-N-Z5L	$	24v DC	210 bar
4DWG6-C-60-AC220-N-Z5L	$	240v AC	160 bar
4DWG6-D-60-DC12-N-Z5L	$	12v DC	210 bar
4DWG6-D-60-DC24-N-Z5L	$	24v DC	210 bar
4DWG6-D-60-AC220-N-Z5L	$	240v AC	160 bar
4DWG6-HA-60-DC12-N-Z5L	$	12v DC	210 bar
4DWG6-HA-60-DC24-N-Z5L	$	24v DC	210 bar
4DWG6-HA-60-AC220-N-Z5L	$	240v AC	160 bar

CETOP 3 SOLENOID & MANUAL VALVES

Cetop 3 Valves w/ single coils & LED DIN plugs (...continued)

Recommended maximum flow 40 lpm @ 210 bar

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage	Max Press Tank
4DWG6-EB-60-DC12-N-Z5L	$	12v DC	210 bar
4DWG6-EB-60-DC24-N-Z5L	$	24v DC	210 bar
4DWG6-EB-60-AC220-N-Z5L	$	240v AC	160 bar
4DWG6-EA-60-DC12-N-Z5L	$	12v DC	210 bar
4DWG6-EA-60-DC24-N-Z5L	$	24v DC	210 bar
4DWG6-EA-60-AC220-N-Z5L	$	240v AC	160 bar

Cetop 3 Valves w/ dual coils, LED DIN plugs & manual lever

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage	Max Press Tank
4DWG6C-EL-E/DC12Z5L	$	12v DC	160 bar
4DWG6C-EL-E/DC2425L	$	24v DC	160 bar
4DWG6C-EL-E/DC220Z5L	$	240v AC	160 bar
4DWG6E-EL-E/DC12Z5L	$	12v DC	160 bar
4DWG6E-EL-E/DC24Z5L	$	24v DC	160 bar
4DWG6E-EL-E/DC220Z5L	$	240v AC	160 bar
4DWG6J-EL-E/DC12Z5L	$	12v DC	160 bar
4DWG6J-EL-E/DC24Z5L	$	24v DC	160 bar
4DWG6J-EL-E/DC220Z5L	$	240v AC	160 bar
4DWG6G-EL-E/DC12Z5L	$	12v DC	160 bar
4DWG6G-EL-E/DC24Z5L	$	24v DC	160 bar
4DWG6G-EL-E/DC220Z5L	$	240v AC	160 bar
4DWG6H-EL-E/DC12Z5L	$	12v DC	160 bar
4DWG6H-EL-E/DC2425L	$	24v DC	160 bar
4DWG6H-EL-E/DC220Z5L	$	240v AC	160 bar

CETOP 3 MANUAL VALVES

Cetop 3 Manual Valves

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage	Max Press Tank	Transition
4DWMG6-E-50	$	Manual	210 bar	Closed
4DWMG6-H-50	$	Manual	210 bar	Open
4DWMG6-J-50	$	Manual	210 bar	A+B to tank
4DWMG6-G-50	$	Manual	210 bar	Open
4DWMG6-G-50-F	$	Manual Spring Return Detent	210 bar	Open
4DWMG6-C-50	$	Manual	210 bar	Open
4DWMG6-C-50-F	$	Manual Spring Return Detent	210 bar	Open

CETOP 5 SOLENOID VALVES

Aidro Cetop 5 Solenoid Valves

ED Series (Cetop 5 flow rate with Cetop 3 coils)

	SOLENOID
Nominal Flow Rate	100 Ipm
Maximum Recommended Flow	125 Ipm
Maximum Nominal Pressure P,A,B	320 bar
Maximum Pressure on T Port	210 bar
Duty Cycle	100%
Bolts (single valve)	M6x35mm (tighten to 12Nm)

Typical Diagrams

Typical rp-Q curves for valves HD5-ED-* in standard configuration. Measured with mineral oil at 32mm²/s and T=40°C

Spool	P-A	P-B	A-T	B-T	P-T
0C	1	1	1	1	1
1C	1	1	2	2	–
3C	1	1	1	1	–
4C	4	4	4	4	1
1LL	2	2	3	3	–
1LLb	2	2	3	3	–

Hydraulic Limit of Use

rp-Q characteristics limits for safe use of HD5-ED-* solenoid operated valves. Measured with mineral oil at 32mm²/s and T=40°C

Spool	Limit	Spool	Limit
1C	1	4ML	3
4C	3	1ML	1
0C	1	1MLb	1
3C	2	1LLb	1
1LL	1	4MLb	3
3ML	2	–	–

HYDRAULIC FLUID

Seals and materials used on standard HD5-* valves are fully compatible with hydraulic
fluids of mineral base, upgrading with antifoaming and antioxidising agents.

The hydraulic fluid must be kept clear and filtered to ISO4406 class 19/17/14, or better,
and used in a recommended viscosity range from 10cSt to 60cSt.

Cetop 5 Solenoid Valves (AIDRO)

ED Series (Cetop 5 flow rate with Cetop 3 coils)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage
HD5-ED-0C-012C/10	$	12v DC
HD5-ED-0C-024C/10	$	24v DC
HD5-ED-0C-230A/10	$	230v AC
HD5-ED-0C-115A/10	$	115v AC
HD5-ED-1C-012C/10	$	12v DC
HD5-ED-1C-024C/10	$	24v DC
HD5-ED-1C-230A/10	$	230v AC
HD5-ED-1C-115A/10	$	115v AC
HD5-ED-3C-012C/10	$	12v DC
HD5-ED-3C-024C/10	$	24v DC
IID5-ED-3C-230A/10	$	230v AC
HD5-ED-3C-115A/10	$	115v AC
HD5-ED-4C-012C/10	$	12v DC
IID5-ED-4C-024C/10	$	24v DC
HD5-ED-4C-230A/10	$	230v AC
HD5-ED-4C-115A/10	$	115v AC

Cetop 5 Solenoid Valves (AIDRO)

ED Series (Cetop 5 flow rate with Cetop 3 coils)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage
HD5-ED-OLL-012C/10	$	12v DC
HD5-ED-OLL-024C/10	$	24v DC
HD5-ED-OLL-230A/10	$	230v AC
HD5-ED-OLL-115A/10	$	115v AC
HD5-ED-OML-012C/10	$	12v DC
HD5-ED-OML-024C/10	$	24v DC
HD5-ED-OML-230A/10	$	230v AC
HD5-ED-OML-115A/10	$	115v AC
HD5-ED-1LL-012C/10	$	12v DC
HD5-ED-1LL-024C/10	$	24v DC
HD5-ED-1LL-230A/10	$	230v AC
HD5-ED-1LL-115A/10	$	115v AC
HD5-ED-1ML-012C/10	$	12v DC
HD5-ED-1ML-024C/10	$	24v DC
HD5-ED-1ML-230A/10	$	230v AC
HD5-ED-1ML-115A/10	$	115v AC
HD5-ED-3ML-012C/10	$	12v DC
HD5-ED-3ML-024C/10	$	24v DC
HD5-ED-3ML-230A/10	$	230v AC
HD5-ED-3ML-115A/10	$	115v AC
HD5-ED-4ML-012C/10	$	12v DC
HD5-ED-4ML-024C/10	$	24v DC
HD5-ED-4ML-230A/10	$	230v AC
HD5-ED-4ML-115A/10	$	115v AC

Aidro Cetop 5 Solenoid Valves

ES Series (high power BO5 coils)

	SOLENOID
Nominal Flow Rate	120 Ipm
Maximum Recommended Flow	See graphs
Maximum Nominal Pressure P,A,B	320 bar
Maximum Pressure on T Port	210 bar
Duty Cycle	100%
Bolts (single valve)	M6x35mm (tighten to 12Nm)

Typical Diagrams

Typical rp-Q curves for valves HD5-ES-* in standard configuration. Measured with mineral oil at 32mm²/s and T=40°C.

Spool	P-A-	P-B	A-T	B-T	P-T
0C	1	1	2	2	1
1C	1	1	2	2	–
3C	1	1	2	2	–
4C	3	3	4	4	1
OLL	1	1	1	3	–
1LL	1	1	2	2	–
0ML	–	1	2	–	1
1ML	–	1	2	–	–
3ML	–	1	2	–	–
4ML	3	–	–	4	1

Hydraulic Limit of Use

rp-Q characteristics limits for safe use of HD5-ES-* solenoid operated valves. Measured with mineral oil at 32mm²/s and T=40°C.

Spool	Limit	Spool	Limit
0C	1	4C	3
1C	1	OLL	2
0ML	1	1LL	2
1ML	1	1LLb	2
3C	5	4MLb	3
3ML	5

HYDRAULIC FLUID

Seals and materials used on standard HD5-* valves are fully compatible with hydraulic
fluids of mineral base, upgrading with antifoaming and antioxidising agents.

The hydraulic fluid must be kept clear and filtered to ISO4406 class 19/17/14, or better,
and used in a recommended viscosity range from 10cSt to 60cSt.

Cetop 5 Solenoid Valves (AIDRO) High Power

ES Series (high power BO5 coils)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage
HD5-ES-0C-012C/20	$	12v DC
HD5-ES-0C-024C/20	$	24v DC
HD5-ES-0C-230A/20	$	230v AC
HD5-ES-0C-115A/20	$	115v AC
HD5-ES-1C-012C/20	$	12v DC
HD5-ES-1C-024C/20	$	24v DC
HD5-ES-1C-230A/20	$	230v AC
HD5-ES-1C-115A/20	$	115v AC
HD5-ES-3C-012C/20	$	12v DC
HD5-ES-3C-024C/20	$	24v DC
HD5-ES-3C-230A/20	$	230v AC
HD5-ES-3C-115A/20	$	115v AC
HD5-ES-4C-012C/20	$	12v DC
HD5-ES-4C-024C/20	$	24v DC
HD5-ES-4C-230A/20	$	230v AC
HD5-ES-4C-115A/20	$	115v AC

Cetop 5 Solenoid Valves (AIDRO) High Power

ES Series (high power BO5 coils)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage
HD5-ES-OLL-012C/20	$	12v DC
HD5-ES-OLL-024C/20	$	24v DC
HD5-ES-OLL-230A/20	$	230v AC
HD5-ES-OLL-115A/20	$	115v AC
HD5-ES-OML-012C/20	$	12v DC
HD5-ES-OML-024C/20	$	24v DC
HD5-ES-OML-230A/20	$	230v AC
HD5-ES-OML-115A/20	$	115v AC
HD5-ES-1LL-012C/20	$	12v DC
HD5-ES-1LL-024C/20	$	24v DC
HD5-ES-1LL-230A/20	$	230v AC
HD5-ES-1LL-115A/20	$	115v AC
HD5-ES-1ML-012C/20	$	12v DC
HD5-ES-1ML-024C/20	$	24v DC
HD5-ES-1ML-230A/20	$	230v AC
HD5-ES-1ML-115A/20	$	115v AC
HD5-ES-3ML-012C/20	$	12v DC
HD5-ES-3ML-024C/20	$	24v DC
HD5-ES-3ML-230A/20	$	230v AC
HD5-ES-3ML-115A/20	$	115v AC
HD5-ES-4ML-012C/20	$	12v DC
HD5-ES-4ML-024C/20	$	24v DC
HD5-ES-4ML-230A/20	$	230v AC
HD5-ES-4ML-115A/20	$	115v AC

Cetop 5 Valves w/ dual coils & LED DIN plugs

Recommended maximum flow 80 lpm @ 210 bar

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage	Max Press Tank
4DWG10-E-30-DC12-N-Z5L	$	12v DC	210 bar
4DWG10-E-30-DC24-N-Z5L	$	24v DC	210 bar
4DWG10-E-30-AC220-N-75L	$	240v AC	160 bar
4DWG10-H-30-DC12-N-Z5L	$	12v DC	210 bar
4DWG10-H-30-DC24-N-Z5L	$	24v DC	210 bar
4DWG10-H-30-AC220-N-Z5L	$	240v AC	160 bar
4DWG10-J-30-DC12-N-Z5L	$	12v DC	210 bar
4DWG10-J-30-DC24-N-Z5L	$	24v DC	210 bar
4DWG10-J-30-AC220-N-Z5L	$	240v AC	160 bar
4DWG10-G-30-DC12-N-Z5L	$	12v DC	210 bar
4DWG10-G-30-DC24-N-Z5L	$	24v DC	210 bar
4DWG10-G-30-AC220-N-Z5L	$	240v AC	160 bar

CETOP 5 SOLENOID & AUTO-CYCLING VALVES

Cetop 5 Valves w/ single coils & LED DIN plugs

ED Series (Cetop 5 flow rate with Cetop 3 coils)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage	Max Press Tank
4DWG10-C-30-DC12-N-Z5L	$	12v DC	210 bar
4DWG10-C-30-DC24-N-Z5L	$	24v DC	210 bar
4DWG10-C-30-AC220-N-Z5L	$	240v AC	160 bar
4DWG10-D-30-DC12-N-Z5L	$	12v DC	210 bar
4DWG10-D-30-DC24-N-Z5L	$	24v DC	210 bar
4DWG10-D-30-AC220-N-Z5L	$	240v AC	160 bar
4DWG10-HA-30-DC12-N-Z5L	$	12v DC	210 bar
4DWG10-HA-30-DC24-N-Z5L	$	24v DC	210 bar
4DWG10-HA-30-AC220-N-Z5L	$	240v AC	160 bar
4DWG10-EB-30-DC12-N-Z5L	$	12v DC	210 bar
4DWG10-EB-30-DC24-N-Z5L	$	24v DC	210 bar
4DWG10-E3-30-AC220-N-Z5L	$	240v AC	160 bar
4DWG10-EA-30-DC12-N-Z5L	$	12v DC	210 bar
4DWG10-EA-30-DC24-N-Z5L	$	24v DC	210 bar
4DWG10-EA-30-AC220-N-Z5L	$	240v AC	160 bar

Auto-Cycling Valve

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Description
ES610-41	$	Cetop 3 autocycling valve
ES610-42	$	Cetop 5 autocycling valve

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Description

ES610-41

Cetop 3 autocycling valve

ES610-42

Cetop 5 autocycling valve

CETOP 7 PILOT-OPERATED VALVES & SUBPLATES

Cetop 7 Pilot-Operated Valves w/ coils & LED DIN plugs

Recommended maximum flow 200 lpm @ 210 bar

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Coil Voltage	Max Press Tank
4DWHG16E60/DC12ET	$	12v DC	160 bar
4DWHG16E60/DC24ET	$	24v DC	160 bar
4DWHG16E60/AC220ET	$	240v AC	100 bar
4DWHG16H60/DC12ET	$	12v DC	160 bar
4DWHG16H60/DC24ET	$	24v DC	160 bar
4DWHG16H60/AC220ET	$	240v AC	100 bar
4DWHG16J60/DC12ET	$	12v DC	160 bar
4DWHG16J60/DC24ET	$	24v DC	160 bar
4DWHG16J60/AC220ET	$	240v AC	100 bar
4DWHG16G60/DC12ET	$	12v DC	160 bar
4DWHG16G60/DC24ET	$	24v DC	160 bar
4DWHG16G60/AC220ET	$	240v AC	100 bar
4DWHG16C60/DC12ET	$	12v DC	160 bar
4DWHG16C60/DC24ET	$	24v DC	160 bar
4DWHG16C60/AC220ET	$	240v AC	100 bar
4DWHG16D60/DC12ET	$	12v DC	160 bar
4DWHG16D60/DC24ET	$	24v DC	160 bar
4DWHG16D60/AC220ET	$	240v AC	100 bar

Cetop 7 Subplates

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Stations	Function	Ports	Material
BS72S	$	1	Rear Ports	1″ BSPP	Steel

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Stations

Function

Ports

Material

BS72S

Rear Ports

1″ BSPP

Steel

COILS

Valve Coils (4DWG6)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Voltage	Amp	Core Size	Length	Connector	Valve
COIL-06-12VDC	$	12v DC	2.66a	23.5mm	50.7mm	DIN 43650-A	4DWG6
COIL-06-24VDC	$	24v DC	1.45a	23.5mm	50.7mm	DIN 43650-A	4DWG6
COIL-06-48VDC	$	48v DC	0.7a	23.5mm	50.7mm	DIN 43650-A	4DWG6
COIL-06-110VAC	$	110v AC	0.35a	23.5mm	50.7mm	DIN 43650-A	4DWG6
COIL-06-220VAC	$	220v AC	0.17a	23.5mm	50.7mm	DIN 43650-A	4DWG6

Valve Coils (4DWG10)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Voltage	Amp	Core Size	Length	Connector	Valve
COIL-10-12VDC	$	12v DC	4.0a	31.8mm	75.2mm	DIN 43650-A	4DWG10
COIL-10-24VDC	$	24v DC	2.0a	31.8mm	75.2mm	DIN 43650-A	4DWG10
COIL-10-110VAC	$	110v AC	0.5a	31.8mm	75.2mm	DIN 43650-A	4DWG10
COIL-10-220VAC	$	220v AC	0.25a	31.8mm	75.2mm	DIN 43650-A	4DWG10

Valve Coils (HD5-ES High Power)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Voltage	Amp	Core Size	Length	Connector	Valve
B05-12C	$	12v DC	3.17	31mm	73.5	DIN 43650-A	HD5 -ES
B05-24C	$	24v DC	1.73	31mm	73.5	DIN 43650-A	HD5 -ES
B05-48C	$	48v AC	0.865	31mm	73.5	DIN 43650-A	HD5-ES
B05-115A	$	115v AC	0.40	31mm	73.5	DIN 43650-A	HD5-ES
B05-230A	$	230v AC	0.20	31mm	73.5	DIN 43650-A	HD5-ES

Valve Coils (HD3-ES / HD5-ED Low Power)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Voltage	Amp	Core Size	Length	Connector	Valve
B03-12R3	$	12v DC	2.5	22 mm	52 mm	DIN 43650-A	HD3-ES / HD5-ED
B03-24R4	$	24v DC	1.0	22 mm	52 mm	DIN 43650-A	HD3-ES / HD5-ED
B03-48C	$	48v AC	0.6	22 mm	52 mm	DIN 43650-A	HD3-ES / HD5-ED
B03-115A	$	115v AC	0.26	22 mm	52 mm	DIN 43650-A	HD3-ES / HD5-ED
B03-230A	$	230v AC	0.14	22 mm	52 mm	DIN 43650-A	HD3-ES / HD5-ED

SPARE PARTS, BOLT KITS & DIN PLUGS

HD3-ES / HD5-ED Spare Parts & Bolt Kits

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Description
KIT-03K	$	Manual override nut
TO3-T	$	Soft shift kit
TAP-03-OR	$	Nut & spring kit
HD3-01-BK	$	Cetop 3 – 1 section bolt kit
HD3-02-BK	$	Cetop 3 – 2 section bolt kit
HD3-03-BK	$	Cetop 3 – 3 section bolt kit
HD5-01-BK-ED	$	Cetop 5 – 1 section bolt kit (ES Series)
HD5-02-BK-ED	$	Cetop 5 – 2 section bolt kit (ED Series)
HD5-03-BK-ED	$	Cetop 5 – 3 section bolt kit (ED Series)

HD3-ES / HD5-ED Spare Parts & Bolt Kits

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Description
WK-05	$	Manual override nut
TAP-05-20	$	Nut & spring kit
HD5-01-BK-ES	$	Cetop 5 – 1 section bolt kit (ES Series)
HD5-02-BK-ES	$	Cetop 5 – 2 section bolt kit (ES Series)
HD5-03-BK-ES	$	Cetop 5 – 3 section bolt kit (ES Series)

Manual Override Nut (4DWG6)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Description	Valve
4DWE6-DT-M-S	$	Fits 14mm solenoid thread	4DWG6
4DWE6-DT-M-L	$	Fits 22mm solenoid thread	4DWG6

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Description

Valve

4DWE6-DT-M-S

Fits 14mm solenoid thread

4DWG6

4DWE6-DT-M-L

Fits 22mm solenoid thread

4DWG6

DIN Plugs

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Description	DIN Size	Terminals	Body	LED
DP-IP67-AC/DC-250	$	1-250V AC+DC, IP67	DIN 43650-A	3	Clear	Yes
DP-IP67-AC/DC-38	$	1-38V AC+DC, IP67	DIN 43650-A	3	Clear	Yes
DP-IP67-AC/DC-3M	$	1-38V AC+DC, 3m Cable, IP67	DIN 43650-A	3	Clear	Yes
DP-LED-AC	$	AC	DIN 43650-A	3	Clear	Yes
DP-LED-DC	$	DC	DIN 43650-A	3	Clear	Yes
DP-REC-LV	$	Rectifier AC to DC (1-48v)	DIN 43650-A	3	Clear	Yes
DP-REC	$	Rectifier AC to DC (70-250v)	DIN 43650-A	3	Clear	No

CETOP 3 SUBPLATES

Flow Control Subplates (Meter In)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Function	Maximum Recommended Flow Rate	Maximum Nominal Pressure
AM3-FX-AB/10	$	Flow control on A & B, meter in	60 Ipm	320 bar
AM3-FX-A/10	$	Flow control on A, meter in	60 Ipm	320 bar
AM3-FX-B/10	$	Flow control on B, meter in	60 Ipm	320 bar

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Function

Maximum Recommended Flow Rate

Maximum Nominal Pressure

AM3-FX-AB/10

Flow control on A & B, meter in

60 Ipm

320 bar

AM3-FX-A/10

Flow control on A, meter in

60 Ipm

320 bar

AM3-FX-B/10

Flow control on B, meter in

60 Ipm

320 bar

Flow Control Subplates (Meter Out)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Function	Maximum Recommended Flow Rate	Maximum Nominal Pressure
AM3-FC-AB/10	$	Flow control on A & B, meter in	60 Ipm	320 bar
AM3-FC-A/10	$	Flow control on A, meter in	60 Ipm	320 bar
AM3-FC-B/10	$	Flow control on B, meter in	60 Ipm	320 bar

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Function

Maximum Recommended Flow Rate

Maximum Nominal Pressure

AM3-FC-AB/10

Flow control on A & B, meter in

60 Ipm

320 bar

AM3-FC-A/10

Flow control on A, meter in

60 Ipm

320 bar

AM3-FC-B/10

Flow control on B, meter in

60 Ipm

320 bar

Pilot Check Subplates

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Function	Maximum Recommended Flow Rate	Maximum Nominal Pressure
AM3-CP-AB/10	$	Pilot check on A & B	60 Ipm	320 bar
AM3-CP-A/10	$	Pilot check on A	60 Ipm	320 bar
AM3-CP-B/10	$	Pilot check on B	60 Ipm	320 bar

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Function

Maximum Recommended Flow Rate

Maximum Nominal Pressure

AM3-CP-AB/10

Pilot check on A & B

60 Ipm

320 bar

AM3-CP-A/10

Pilot check on A

60 Ipm

320 bar

AM3-CP-B/10

Pilot check on B

60 Ipm

320 bar

Pressure Reducing Subplates (No Check)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Function	Pressure Reducing Range	Maximum Recommended Flow Rate	Maximum Nominal Pressure
Part #		Function	Pressure Reducing Range	Maximum Recommended Flow Rate	Maximum Nominal Pressure	AM3-RO-P-32/10	$	Pressure reducing in P	3-35 bar	60 Ipm	320 bar
AM3-RO-A-32/10	$	Pressure reducing in A	3-35 bar	60 Ipm	320 bar
AM3-RO-B-32/10	$	Pressure reducing in B	3-35 bar	60 Ipm	320 bar
AM3-RO-P-6.3/10	$	Pressure reducing in P	10-70 bar	60 Ipm	320 bar
AM3-RO-A-6.3/10	$	Pressure reducing in A	10-70 bar	60 Ipm	320 bar
AM3-RO-B-6.3/10	$	Pressure reducing in B	10-70 bar	60 Ipm	320 bar
AM3 RO-P-12.5/10	$	Pressure reducing in P	30-140 bar	60 Ipm	320 bar
AM3-RO-A-12.5/10	$	Pressure reducing in A	30-140 bar	60 Ipm	320 bar
AM3-RO-B-12.5/1 0	$	Pressure reducing in B	30-140 bar	60 Ipm	320 bar
AM3-RO-P-25/10	$	Pressure reducing in P	60-280 bar	60 Ipm	320 bar
AM3-RO-A-25/10	$	Pressure reducing in A	60-280 bar	60 Ipm	320 bar
AM3-RO-B-25/10	$	Pressure reducing in B	60-280 bar	60 Ipm	320 bar

Pressure Reducing Subplates (With Check)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Function	Pressure Range	Maximum Recommended Flow Rate	Maximum Nominal Pressure
Part #		Function	Pressure Range	Maximum Recommended Flow Rate	Maximum Nominal Pressure	AM3-RP-P-20/10	$	Pressure reducing in P	30-140 bar	60 lpm	320 ba
AM3-RP-AC-20/10	$	Pressure reducing in A	30-140 bar	60 lpm	320 ba
HD3-02-RP-BK	$	2 section bolt kit
HD3-03-RP-BK	$	2 section bolt kit

Direct Acting Pressure Relief Subplates

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Function	Pressure Range	Maximum Recommended Flow Rate	Maximum Nominal Pressure
Part #		Function	Pressure Range	Maximum Recommended Flow Rate	Maximum Nominal Pressure	AM3-MO-P-12.5/10	$	Direct acting relief on P	25-125 bar	60 Ipm	320 bar
AM3-MO-B-12.5/10	$	Direct acting relief on B	25-125 bar	60 Ipm	320 bar
AM3 MO BA 12.5/10	$	Direct acting relief on A & B	25-125 bar	60 Ipm	320 bar
AM3-MO-P-20/10	$	Direct acting relief on P	40-250 bar	60 Iprn	320 bar
AM3-MO-B-20/10	$	Direct acting relief on B	40-250 bar	60 Ipm	320 bar
AM3-MO-BA-20-20/10	$	Direct acting relief on A & B	40-250 bar	60 Ipm	320 bar
AM3-MO-P-32/10	$	Direct acting relief on P	100-320 bar	60 Ipm	320 bar
AM3-MO-B-32/10	$	Direct acting relief on B	100-320 bar	60 Ipm	320 bar
AM3-MO-BA-32-32/10	$	Direct acting relief on A & B	100-320 bar	60 Ipm	320 bar

Pilot Operated Pressure Relief Subplates

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Function	Pressure Range	Maximum Recommended Flow Rate	Maximum Nominal Pressure
Part #		Function	Pressure Range	Maximum Recommended Flow Rate	Maximum Nominal Pressure	AM3-MP-P-6.3/10	$	Pilot operated relief on P	10-70 bar	60 Ipm	320 bar
AM3-MP-B-6.3/10	$	Pilot operated relief on B	10-70 bar	60 Ipm	320 bar
AM3-MP-BA-6.3-6.3/10	$	Pilot operated relief on A & B	10-70 bar	60 Ipm	320 bar
AM3-MP-P-12.5/10	$	Pilot operated relief on P	10-140 bar	60 Ipm	320 bar
AM3 MP B 12.5/10	$	Pilot operated relief on B	10-140 bar	60 Ipm	320 bar
AM3-MP-BA-12.5-12.5/10	$	Pilot operated relief on A & B	10-140 bar	60 Ipm	320 bar
AM3-MP-P-20/10	$	Pilot operated relief on P	20-210 bar	60 Ipm	320 bar
AM3-MP-B-20/10	$	Pilot operated relief on B	20-210 bar	60 Ipm	320 bar
AM3-MP-BA-20-20/10	$	Pilot operated relief on A & B	20-210 bar	60 Ipm	320 bar
AM3-MP-P-32/10	$	Pilot operated relief on P	20-320 bar	60 Ipm	320 bar
AM3-MP-B-32/10	$	Pilot operated relief on B	20-320 bar	60 Ipm	320 bar
AM3-MP-BA-32-32/10	$	Pilot operated relief on A & B	20-320 bar	60 Ipm	320 bar

Cetop 3 Counterbalance Valves

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Maximum Pressure	Centre	Maximum Flow	Ratio
VBCS0601S	$	210 bar	Open	40 Ipm	1:4.25
VBCS0602S	$	350 bar	Open	40 Ipm	1:4.25
VBCT0601S	$	210 bar	Closed	40 Ipm	1:4.25
VBCT0602S	$	350 bar	Closed	40 Ipm	1:4.25

2-Way Pressure Compensator Valve (Meter In)

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Maximum Pressure

Maximum Flow

Fixed Differential Setting

AM3-PC-P/10

320 bar

32 Ipm

10 bar

3-Way Pressure Compensator Valve with Load

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Maximum Pressure

Maximum Flow

Adj. Differential Setting

AM3-LS-P3/20

320 bar

40 Ipm

5-40 bar

Regenerative Valve

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Maximum Pressure

Maximum Flow

Function

AM3-RGT-AP/10

350 bar

30 Ipm

Flow from A-P

Pilot Check Subplates

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Maximum Pressure

Function

Z2DS6-50

250 bar

Pilot check on A & B

Z2DS6A-50

250 bar

Pilot check on A

Z2DS6B-50

250 bar

Pilot check on B

Flow Control Subplates (Steel Body)

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Maximum Pressure

Function

Z2FDS630-S

250 bar

Flow control on A & B, meter in

Z2FDS630-S2

250 bar

Flow control on A & B, meter out

Pressure Reducing Subplates (Steel Body)

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Maximum Pressure

Function

ZPR6DP2-30-210-Y-M

250 bar

Pressure reducing in P, 70-210 bar

ZPR6DA2-30-210-Y-M

250 bar

Pressure reducing in A, 70-210 bar

ZPR6DB2-30-210-Y-M

250 bar

Pressure reducing in B, 70-210 bar

Relief Subplates (Steel Body)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Maximum Pressure	Function
ZPB6VP-1-315	$	250 bar	Relief on P, 70-250 bar
ZPB6VA-1-315	$	250 bar	Relief on A, 70-250 bar
ZPB6VB-1-315	$	250 bar	Relief on B, 70-250 bar
ZPB6VC-1-315	$	250 bar	Relief on A & B, 70-250 bar

CETOP 5 SUBPLATES

Flow Control Subplates (Meter In)

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Function

Maximum Recommended Flow Rate

Maximum Nominal Pressure

AM5-FX-AB/10

Flow control on A & B, meter in

100 lpm

320 bar

AM5-FX-A/10

Flow control on A, meter in

100 lpm

320 bar

AM5-FX-B/10

Flow control on B, meter in

100 lpm

320 bar

Flow Control Subplates (Meter Out)

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Function

Maximum Recommended Flow Rate

Maximum Nominal Pressure

AM5-FC-AB/10

Flow control on A & B, meter in

100 lpm

320 bar

AM5-FC-A/10

Flow control on A, meter in

100 lpm

320 bar

AM5-FC-B/10

Flow control on 8, meter in

100 lpm

320 bar

Pilot Check Subplates

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Function	Maximum Recommended Flow Rate	Maximum Nominal Pressure
Part #		Function	Maximum Recommended Flow Rate	Maximum Nominal Pressure	AM5-CP-AB/10	$	Pilot check on A & B	100 lpm	320 bar
AM5-CP-A/10	$	Pilot check on A	100 lpm	320 bar
AM5-CP-B/10	$	Pilot check on B	100 lpm	320 bar
AM5-CP-AB/20	$	Pilot check on A & B	140 lpm	350 bar
AM5-CP-A/20	$	Pilot check on A	140 lpm	350 bar
AM5-CP-B/20	$	Pilot check on B	140 lpm	350 bar

Pressure Reducing Subplates (With Check)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Function	Pressure Range	Max Recommended Flow Rate	Regulated Line Flow Rate	Max Nominal Pressure
Part #		Function	Pressure Range	Max Recommended Flow Rate	Regulated Line Flow Rate	Max Nominal Pressure	AM5-RP-A-6.3/10	$	Pressure reducing in A	5-70 bar	100 lpm	80 lpm	320 bar
AM5-RP-B-6.3/10	$	Pressure reducing in B	5-70 bar	100 lpm	80 lpm	320 bar
AM5-RP-P-6.3/10	$	Pressure reducing in P	5-70 bar	100 lpm	80 lpm	320 bar
AM5-RP-A-20/10	$	Pressure reducing in A	16-210 bar	100 lpm	80 lpm	320 bar
AM5-RP-B-20/10	$	Pressure reducing in B	16-210 bar	100 lpm	80 lpm	320 bar
AM5-RP-P-20/10	$	Pressure reducing in P	16-210 bar	100 lpm	80 lpm	320 bar

Pilot Operated Pressure Relief Subplates

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Function	Pressure Range	Max Recommended Flow Rate	Max Nominal Pressure
Part #		Function	Pressure Range	Max Recommended Flow Rate	Max Nominal Pressure	AM5-MP-P-6.3/10	$	Pilot operated relief on P	10-70 bar	100 lpm	320 bar
AM5-MP-A-6.3/10	$	Pilot operated relief on B	10-70 bar	100 lpm	320 bar
AM5-MP-BA-6.3-6.3/10	$	Pilot operated relief on A & B	10-70 bar	100 lpm	320 bar
AM5-MP-P-12.5/10	$	Pilot operated relief on P	10-140 bar	100 lpm	320 bar
AM5-MP-A-12.5/10	$	Pilot operated relief on B	10-140 bar	100 lpm	320 bar
AM5-MP-BA-12.5-12.5/10	$	Pilot operated relief on A & B	10-140 bar	100 lpm	320 bar
AM5-MP-P-20/10	$	Pilot operated relief on P	20-210 bar	100 lpm	320 bar
AM5-MP-A-20/10	$	Pilot operated relief on B	20-210 bar	100 lpm	320 bar
AM5-MP-BA-20-20/10	$	Pilot operated relief on A & B	20-210 bar	100 lpm	320 bar
AM5-MP-P-32/10	$	Pilot operated relief on P	20-320 bar	100 lpm	320 bar
AM5-MP-A-32/10	$	Pilot operated relief on B	20-320 bar	100 lpm	320 bar
AM5-MP-BA-32-32/10	$	Pilot operated relief on A & B	20-320 bar	100 lpm	320 bar

Regenerative Valve

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Maximum Pressure

Maximum Flow

Function

AM5-RGT

350 bar

80 Ipm

Flow from B-P

Pilot Check Subplates (Steel Body)

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Maximum Pressure

Function

Z2DS10-10

250 bar

Pilot check on A & B

Z2DS10A-10

250 bar

Pilot check on A

Z2DS10B-10

250 bar

Pilot check on B

Flow Control Subplates (Steel Body)

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Maximum Pressure

Function

Z2FDS1030-S

250 bar

Flow control on A & 3, meter in

Z2FDS1030-S2

250 bar

Flow control on A & B, meter out

Pressure Reducing Subplates (Steel Body)

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Maximum Pressure

Function

ZPR10DP2-30-210-Y-M

250 bar

Pressure reducing in P, 70-210 bar

ZPR10DA2-30-210-Y-M

250 bar

Pressure reducing in A, 70-210 bar

ZPR10DB2-30-210-Y-M

250 bar

Pressure reducing in B, 70-210 bar

Relief Subplates (Steel Body)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Maximum Pressure	Function
Z2PB10VP-1-315	$	250 bar	Relief on P, 70-250 bar
Z2PB10VA-1-315	$	250 bar	Relief on A, 70-250 bar
Z2PB10VB-1-315	$	250 bar	Relief on B, 70-250 bar
Z2PB10VC-1-315	$	250 bar	Relief on A & B, 70-250 bar

CETOP 3 MANIFOLD SUBPLATES

Cetop 3 Manifold Subplate

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Port Position A/B/P/T	Port Size	Nominal Flow	Maximum Flow	Material
Part #		Port Position A/B/P/T	Port Size	Nominal Flow	Maximum Flow	Material	EA06-07-38	$	Rear	3/8″ BSPP	30 lpm	70 lpm	Aluminium
ES06-07-38	$	Rear	3/8″ BSPP	30 lpm	70 lpm	Steel
ES06-08-38	$	Side	3/8″ BSPP	30 lpm	70 lpm	Steel
ES06-09-38	$	Side	3/8″ BSPP	30 lpm	70 lpm	Steel
PJ21286	$	Side	3/8″ BSPP	30 lpm	70 lpm	Aluminium
EA06-09-38	$	Side	3/8″ BSPP	30 lpm	70 lpm	Aluminium
EA06-08-38	$	Side Parallel	3/8″ BSPP	30 lpm	70 lpm	Aluminium

Cetop 3 Manifold Subplates

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Description	Material
ES06-00-10	$	Cetop 3 blanking plate	Steel
ES06-00-20-3	$	Cetop 3 crossover plate P-B T-A	Steel
ES06-01-14-1	$	Cetop 3 subplate A + B ports 1/4″ BSPP	Steel
ES06-01-14-4	$	Cetop 3 subplate P + T ports 1/4″ BSPP	Steel

CETOP 3 MANIFOLDS

Cetop 3 Manifolds (1/2” BSPP Ports P+T)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Stations	Relief Bar	A-B	P-T	Unloader Cavity	Gauge Port	Nominal Flow	Max Flow	Material
Part #		Stations	Relief Bar	A-B	P-T	Unloader Cavity	Gauge Port	Nominal Flow	Max Flow	Material	EA06-10-38-1-3-H	$	1	50-220 (M20)	3/8″ BSPP	3/8″ BSPP	n/a	1/4″ BSPP	30 lpm	40 lpm	Aluminium
EA06-14-38-2-4-3-H	$	2	50-220 (M20)	3/8″ BSPP	1/2″ BSPP	Yes (SAE8-2)	1/4″ BSPP	30 lpm	40 lpm	Aluminium
EA06-14-38-3-4-3-H	$	3	50-220 (M20)	3/8″ BSPP	1/2″ BSPP	Yes (SAE8-2)	1/4″ BSPP	30 lpm	40 lpm	Aluminium
EA06-14-38-4-4-3-H	$	4	50-220 (M20)	3/8″ BSPP	1/2″ BSPP	Yes (SAE8-2)	1/4″ BSPP	30 lpm	40 lpm	Aluminium
EA06-14-38-5-4-3-H	$	5	50-220 (M20)	3/8″ BSPP	1/2″ BSPP	Yes (SAE8 2)	1/4″ BSPP	30 lpm	40 lpm	Aluminium
EA06-14-38-6-4-3-H	$	6	50-220 (M20)	3/8″ BSPP	1/2″ BSPP	Yes (SAE8-2)	1/4″ BSPP	30 lpm	40 lpm	Aluminium
EA06-14-38-7-4-3-H	$	7	50-220 (M20)	3/8″ BSPP	1/2″ BSPP	Yes (SAE8-2)	1/4″ BSPP	30 lpm	40 lpm	Aluminium
EA06-14-38-8-4-3-H	$	8	50-220 (M20)	3/8″ BSPP	1/2″ BSPP	Yes (SAE8-2)	1/4″ BSPP	30 lpm	40 lpm	Aluminium

Cetop 3 High Flow Manifolds (3/4” BSPP Ports P+T)

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Stations	Relief Bar	A-B	P-T	Unloader Cavity	Gauge Port	Flow	Material
Part #		Stations	Relief Bar	A-B	P-T	Unloader Cavity	Gauge Port	Flow	Material	EA06-10-12-1-3-H	$	1	20-215 (M20)	1/2- BSPP	1/2- BSPP	n/a	1/4″ BSPP	30 lpm	Aluminium
EA06-28-12-2-4-3-H	$	2	10-240 (SAE10-2)	1/2″ BSPP	3/4″ BSPP	Yes (SAE10 2)	1/4″ BSPP	80 lpm	Aluminium
EA06-28-12-3-4-3-H	$	3	10-240 (SAE10-2)	1/2″ BSPP	3/4″ BSPP	Yes (SAE10-2)	1/4″ BSPP	80 lpm	Aluminium
EA06-28-12-4-4-3-H	$	4	10-240 (SAE10-2)	1/2″ BSPP	3/4″ BSPP	Yes (SAE I 0-2)	1/4″ BSPP	80 lpm	Aluminium
EA06-28-12-5-4-3-H	$	5	10-240 (SAE10-2)	1/2″ BSPP	3/4″ BSPP	Yes (SAE10-2)	1/4″ BSPP	80 lpm	Aluminium
EA06-28-12-6-4-3-H	$	6	10-240 (SAE10-2)	1/2″ BSPP	3/4″ BSPP	Yes (SAE10-2)	1/4″ BSPP	80 lpm	Aluminium

Cetop 3 Series Manifolds (1/2” BSPP Ports P+T)

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Stations

Relief Bar

A-B

P-T

Unloader Cavity

Gauge Port

Nominal Flow

Max Flow

Material

EA06-19-38-2-1-3-H

50-215 (M20)

3/8″ BSPP

1/2″ BSPP

Yes (SAE8-2)

1/4″ BSPP

30 lpm

40 lpm

Aluminium

EA06-19-38-3-1-3-H

50-215 (M20)

3/8″ BSPP

1/2″ BSPP

Yes (SAE8-2)

1/4″ BSPP

30 lpm

40 lpm

Aluminium

EA06-19-38-4-1-3-H

50-215 (M20)

3/8″ BSPP

1/2″ BSPP

Yes (SAE8-2)

1/4″ BSPP

30 lpm

40 lpm

Aluminium

Cetop 3 Manifolds with Relief Valves

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Stations	P-T	A-B	Relief	Material
BPT3A	$	P+T block only	3/8″ BSPP	3/8′ BSPP	SAE8-2	Aluminium
BS3C2	$	1	1/2″ BSPP	3/8″ BSPP	20-210 bar *	Aluminium
BM2AC2	$	2	1/2″ BSPP	3/8′ BSPP	20-210 bar *	Aluminium
BM3AC2	$	3	1/2″ BSPP	3/8″ BSPP	20-210 bar *	Aluminium
BM4AC2	$	4	1/2″ BSPP	3/8′ BSPP	20-210 bar *	Aluminium
BM5AC2	$	5	1/2″ BSPP	3/8′ BSPP	20-210 bar *	Aluminium
BM6AC2	$	6	1/2″ BSPP	3/8′ BSPP	20-210 bar *	Aluminium

Cetop 3 Manifolds without Relief Valves

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Stations	P-T	A-B	Relief	Material
BM2A	$	2	1/2″ BSPP	3/8″ BSPP	–	Aluminium
BM3A	$	3	1/2″ BSPP	3/8″ BSPP	–	Aluminium
BM4A	$	4	1/2″ BSPP	3/8″ BSPP	–	Aluminium
BM5A	$	5	1/2″ BSPP	3/8″ BSPP	–	Aluminium
BM6A	$	6	1/2″ BSPP	3/8″ BSPP	–	Aluminium

CETOP 5 MANIFOLDS & SUBPLATES

Cetop 5 Manifold Subplate

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Stations

Port Size P-T-A-B

Gauge Port

Relief

Material

BPT5A

P+T block only

3/4″ BSPP

1/4″ BSPP

SAE10-2

Aluminium

BS5C2

3/4″ BSPP

1/4″ BSPP

20-210 bar

Aluminium

Cetop 5 Manifold Subplate

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Port Position A-B-P-T

Port Size P-T-A-B

Flow

Material

EA10-02-34

Side

3/4″ BSPP

80 lpm

Aluminium

ES10-02-34

Side

3/4″ BSPP

80 lpm

Steel

ES10-01-34

Rear

3/4″ BSPP

80 lpm

Steel

Cetop 5 Manifolds

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Stations	Relief Bar	A-B	P-T	Unloader Cavity	Gauge Port	Flow	Material
Part #		Stations	Relief Bar	A-B	P-T	Unloader Cavity	Gauge Port	Flow	Material	EA10-09-34-1-3-H	$	1	70-250 (M26)	3/4″ BSPP	3/4″ BSPP	No	1/4″ BSPP	80 lpm	Aluminium
EA10-06-34-2-1-3-H	$	2	70-250 (M26)	1/2″ BSPP	3/4″ BSPP	No	1/4″ BSPP	80 lpm	Aluminium
EA10-06-34-3-1-3-H	$	3	70-250 (M26)	1/2″ BSPP	3/4″ BSPP	No	1/4″ BSPP	80 lpm	Aluminium
EA10-06-34-4-1-3-H	$	4	70-250 (M26)	1/2″ BSPP	3/4- BSPP	No	1/4″ BSPP	80 lpm	Aluminium
EA10-06-34-5-1-3-H	$	5	70-250 (M26)	1/2″ BSPP	3/4″ BSPP	No	1/4″ BSPP	80 lpm	Aluminium
EA10-06-34-6-1-3-H	$	6	70-250 (M26)	1/2″ BSPP	3/4″ BSPP	No	1/4″ BSPP	80 lpm	Aluminium

Cetop 5 Subplates

Part #

List Price Excluding GST

To access PRICES, please click on

“Download Brochure”

Button at the top of the page.

Description

Material

EA610-05-0

Cetop 5 to 3 reducing subplate

Aluminium

Cetop 5 Subplates

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Description	Material
ES10-00-10	$	Cetop 5 blanking plate	Steel
ES 10-00-20-3	$	Cetop 5 crossover plate P-B T-A	Steel
ES10-10-14-1	$	Cetop 5 subplate A + B ports 1/4″ BSPP	Steel
ES 10-10-14-4	$	Cetop 5 subplate P + T ports 1/4″ BSPP	Steel

RELIEF CARTRIDGES & MANIFOLD PLUGS

Direct Acting Relief Cartridge SAE-08

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Size	Pressure Range	Maximum Flow
DRV-S08-04-60-N-H	$	SAE8-2	16-160 bar	30 lpm
DRV-S08-04-135-N-H	$	SAE8-2	25-135 bar	30 lpm
DRV-S08-04-220-N-H	$	SAE8-2	50-220 bar	30 lpm
DRV-S08-04-350-N-H	$	SAE8-2	120-350 bar	30 lpm
CPS-08	$	Steel blanking plug, SAE8-2 cavity

Direct Acting Relief Cartridge SAE-10

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Size	Pressure Range	Maximum Flow
DRV-S10-02-110-N-H	$	SAE10-2	5-110 bar	80 lpm
DRV-S10-02-240-N-H	$	SAE10-2	10-240 bar	80 lpm
DRV-S10-02-350-N-H	$	SAE10-2	50-350 bar	80 lpm
CPS-10	$	Steel blanking plug, SAE10-2 cavity

Direct Acting Relief Cartridge M20

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Size	Pressure Range	Maximum Flow
DRV-M20-02-055-N-H	$	M20	5-55 bar	30 lpm
DRV-M20-02-110-N-H	$	M20	25-110 bar	30 lpm
DRV-M20-02-215-N-H	$	M20	50-215 bar	30 lpm
DRV-M20-02-350-N-H	$	M20	100-350 bar	30 lpm
CPS-M20	$	Steel blanking plug, M20 cavity

Direct Acting Relief Cartridge M26

Part #	List Price Excluding GST To access PRICES, please click on “Download Brochure” Button at the top of the page.	Size	Pressure Range	Maximum Flow
DRV-M26-01-055-N-H	$	M26	5-55 bar	80 lpm
DRV-M26-01-110-N-H	$	M26	25-110 bar	80 lpm
DRV-M26-01-250-N-H	$	M26	75-250 bar	80 lpm
CPS-M26	$	Steel blanking plug, M26 cavity

Spool	P-A-	P-B	A-T	B-T	P-T
0C	1	1	2	2	1
1C	1	1	2	2	–
3C	1	1	2	2	–
4C	3	3	4	4	1
OLL	1	1	1	3	–
1LL	1	1	2	2	–
0ML	–	1	2	–	1
1ML	–	1	2	–	–
3ML	–	1	2	–	–
4ML	3	–	–	4	1

Spool	P-A-	P-B	A-T	B-T	P-T
0C	1	1	2	2	1
1C	1	1	2	2	–
3C	1	1	2	2	–
4C	3	3	4	4	1
OLL	1	1	1	3	–
1LL	1	1	2	2	–
0ML	–	1	2	–	1
1ML	–	1	2	–	–
3ML	–	1	2	–	–
4ML	3	–	–	4	1

Call Charles 0418 641 566 Email: sales@catford.com.au Jamestown South Australia 5491

Cetop Valves, Subplates & Manifolds

Call: 0418 641 566

Email: sales@catford.com.au
